Product Details:
|
HC115 series - Signal (A B), voltage (5V), pulse (100PPR) for Fanuc and other systems.
HC11D series - signal (A B -A -B), voltage (5v), pulse (1 00PPR) suitable for A variety of systems.
HC121 series - signal (A B), voltage (12v), pulse (25PPR) for mitsubishi and other systems.
(Note: The current market can see the system, this type of handwheel is applicable.)
| Model | HC115,HC121,HC11D series |
| Product size | 125*72*28 (mm) |
| The core components | |
| TOSOKU pulse generator (5V100PPR) (12V25PPR) |
Rotary switch TOSOKU MR8A/MR8C
| Adsorption manner | |
| A/Vith magnet adsorption, hook support protection (according to users choice) | |
| Complete spare parts | /Including high grade hook, induding 5 m oil resistant |
| spiral wire, packing box, instruction manual | |
| LED visible indicator | Green |
| Noise immunity | EN50082-2 standard |
Warranty period 12 months
| Net weight | 508.6g |
| Gross weight | 618.1 g |
| System selection | |
| HC115: Voltage (5V), pulse (100PPR) suitable for Fanuc and other systems | |
| HC11D: Voltage (5V), pulse (100PPR) suitable for Siemens and other systems | |
| HC121: voltage (12V), pulse (25PPR) suitable for mitsubishi and other systems | |
